Blackvue

Blackvue DR970X-2CH PLUS 4K UHD 64GB 3-Year Warranty

Blackvue DR970X-2CH PLUS 4K UHD 64GB 3-Year Warranty

Regular price $979.00 AUD
Regular price Sale price $979.00 AUD
Sale Sold out
Shipping calculated at checkout.
  • Blackvue's latest 4K upgrade with new CPU and CMOS image sensor
  • 2CH High-end Premium Package with Cloud Features
  • 4K UHD + 8.4MP Front Recording and 1080P at Rear
  • Next Generation Sony Starvis 2 Sensor at Front
  • 3-Year Warranty with #1 Local Australian Support
  • Made in Korea
General Specifications
Model Name DR970X-2CH Plus
Channel

2CH

Highlights

4K UHD (Front) + Full HD (Rear), 2.4-5GHz Wi-Fi, Cloud, External LTE Module (Optional)

Product Dimensions

Front: Black / 118.6mm(L) x 47.4mm(W) x 36mm(H) / 108g
Rear: Black / 67.3mm(L) x 28mm(W) x 25mm(H) / 25g

Rear Camera Connection

Coaxial cable

Memory Support

microSD card up to 512GB

Recording Modes

Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected).
* When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode.

Parking Mode

YES (hardwiring cable included)

Parking Mode Event Voice Notifications

YES

Imaging Sensor

Front: STARVIS 2 CMOS Sensor (Approx. 8.4 M Pixel)
Rear: STARVISTM CMOS Sensor (Approx. 2.1 M Pixel)

Viewing Angle

Front: Diagonal 146°, Horizonal 125°, Vertical 68°
Rear: Diagonal 131°, Horizonal 107°, Vertical 55°

Resolution Frame Rate

Front: 4K (3840 x 2160) @ 30 fps
Rear: Full HD (1920 x 1080) @ 30 fps
* Frame rate may vary during Wi-Fi streaming.

Video Codec

H.265 (HEVC) / H.264 (AVC)

Image Quality and Bitrate Front/Rear

Highest (Extreme): 60+10 Mbps
Highest: 25+10 Mbps
High: 12+8 Mbps
Normal: 8+6 Mbps

*60Mbps bitrates only support in H.265(HEVC).

Format Free

YES (Adaptive)

Event File Overwrite Protection

YES (up to 50)

SD Card Failure Alert

YES

Scheduled Reboot

YES

Video File Extension

MP4

Wi-Fi

Built-in (802.11 a.b.g.n.ac)

Cloud Compatible

YES

GPS

Built-in (Dual Band : GPS, GLONASS)

Microphone

Built-in

Speaker

Built-in

Impact Sensor

3-Axis Acceleration Sensor

LED Indicators

Front: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED
Rear: Rear Security LED

Button

Format Button: Press and hold format button for 5 seconds, and after a beep, release the button. Then, press again and hold for 5 seconds and release the button after a beep to format the microSD card.
Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings.

Operation Temperature

-20 °C − 70 °C (-4 °F − 158 °F)

Storage Temperature

-20 °C − 80 °C (-4 °F − 176 °F )

High Temp Cut Off

Approx. 75 °C (167 °F)

Backup Battery

Built-in supercapacitor

Input Power

DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)

Power Consumption Hour

Normal Mode (GPS On/2CH): Avg. 480mA /12V
Parking Mode (GPS Off/2CH): Avg. 370mA /12V
* Actual power consumption may vary depending on use conditions and environment.

Certifications

Front : FCC, ISED, CE, UKCA, RCM, RoHS, Telec, WEEE, KC
Rear : FCC, ISED, CE, UKCA, RCM, RoHS, WEEE, KC

Software

BlackVue Viewer
* Windows 7 or higher, Mac Sierra OS X (10.12) or higher
BlackVue Web Viewer
* Chrome 71 or higher, Safari 13.0 or higher

Application

BlackVue Application
* Android 8.0 or higher, iOS 13.0 or higher

Others

Adaptive Format-Free File Management System

Bluetooth Built-in (V2.1+EDR/4.2)
LTE External (Optional)
